Request a quote without obligation
If you have a larger project or are unsure about the required products, we kindly request you to request a quote from us to ask. This is completely without obligation. Please fill in your details and specific wishes and our team will contact you to prepare a detailed, tailor-made quote. This gives you all the information you need to make an informed choice. We have prepared a form to make your request as easy as possible. View here the quotation request form.
Do you have a question or would you like to your advice? Our advisors are ready to help you
Heat pumps and related products are technical and sometimes complex. Every application is unique. In existing buildings or in new construction projects, ‘difficult situations’ for the use of heat pumps (noise, space, appearance). That is why we are happy to think along with you. Please see the 'Downloads' section for brochures and other documentation. If your question has not yet been answered, please contact us by telephone, email or contact form.
| Brand | DHPS |
| Warranty | 3 year |
| Energy class | B |
| Tank temperature (T) max | 95 °C |
| Tank Pressure (P) max | 3 Bar |
| Thermal conductivity | 0.036 W/mK |
| Heat loss | 1.78 kWh/24h |
| Storage volume (exact) | 200 L |
| Dimensions with insulation (mm) | 1235 mm |
| Dimensions with insulation (Ø) | 700 Ø |
| Insulation thickness | 100 mm |
| Tank material | Carbon steel |
| Weight | 67 kg |
| Dimensions in packaging | 700 x 700 x 1750 mm |
| Resistant to hard water | Yes |
| Insulation material | Flexible polyester |
| Storage volume | 200 - 499 liter |
| Hydraulic connection | 5/4" Inch |
| Hydraulic connection | 6/4" Inch |
| Immersion tube | 1/2" Inch |
| Electric element | 6/4" Inch |
| Air vent | 1" Inch |
| Drain valve | 1/2" Inch |
| Heat pump supply | 6/4" Inch |
| Heat pump return | 6/4" Inch |
| Probe connection | 1/2" Inch |
| Supply delivery system | 6/4" Inch |
| Air evacuation | 5/4" Inch |
